034 Dynamic+ ECU Tune for Mk5/Mk6 VW & 8J/8P Audi A3/TT 2.0 TSI | 034-103-2741

034Motorsport is proud to unveil an all-new line of Performance Software for MkV/MkVI Volkswagen GLI/GTI/Eos/Passat/CC/Tiguan and 8J/8P Audi A3/TT model powered by the EA888 Gen 1 2.0 TSI engine!

Flashed directly through your vehicle's OBD-II port, 034Motorsport’s proprietary calibrations for the Bosch MED17 ECU safely and effectively increase the power output of the 2.0 TSI engine. The result is a noticeable improvement in acceleration and throttle response, without any sacrifice in driveability or reliability.

034Motorsport's EA888 Gen 1 2.0 TSI Performance Software was developed entirely in-house on 034Motorsport's Development MkVI Volkswagen GTI. The calibrations were then refined on multiple enthusiast-owned MkV/MkVI Volkswagen 2.0 TSI and 8J/8P Audi A3/TT 2.0 TSI vehicles before release.

Software Features

	Increased Horsepower & Torque Throughout the Powerband
	Improved Power Delivery, Acceleration, and Driving Characteristics

	Available in 91 Octane, 93 Octane, and 100 Octane Calibrations
	Refined Throttle Mapping for Enhanced Throttle Response & Precision

	Raised RPM Limit to 7,000 for Broader Powerband
	Speed Limiter Removed for Increased Top Speed

	Crackle Overrun Enabled in Sport Mode for Stage 2
	Flashed Directly Via the Factory OBD-II Port

034MOTORSPORT EA888 Gen 1 2.0 TSI MED17 ECU PERFORMANCE SOFTWARE COMPARISON

Stage	Fuel	Max HP	Max TQ	Max HP Gain	Max TQ Gain	Rev Limiter	Speed Limiter
Stock	91 Oct	203 HP	218 TQ	NA	NA	6,800 RPM	205kph
Stage 1	91 Oct	231 HP	272 TQ	40 HP @ 4,000 RPM	54 TQ @ 3,800 RPM	7,000 RPM	∞
Stage 2	91 Oct	264 HP	304 TQ	68 HP @ 4,200 RPM	88 TQ @ 4,000 RPM	7,000 RPM	∞
Stage 2	93 Oct	266 HP	306 TQ	68 HP @ 4,150 RPM	89 TQ @ 4,000 RPM	7,000 RPM	∞
Stage 2	100 Oct	271 HP	312 TQ	73 HP @ 4,200 RPM	96 TQ @ 4,000 RPM	7,000 RPM	∞

034MOTORSPORT EA888 Gen 1 2.0 TSI MED17 ECU PERFORMANCE SOFTWARE STAGE DESCRIPTIONS

STAGE 1

034Motorsport Stage 1 Performance Software for the EA888 Gen 1 2.0 TSI engine is engineered to safely increase horsepower and torque with no hardware modifications required. 034Motorsport's proprietary calibrations increase boost while optimizing timing and fueling maps to extract additional power from the 2.0 TSI engine.

Stage 1 Performance Software features a higher redline of 7,000 RPM, resulting in a broader, more usable powerband. In addition to power improvements, 034Motorsport's engineers spent a significant amount of time refining the throttle mapping in order to provide improved throttle response and allow for more precise throttle modulation. Stage 1 Performance Software also enables left foot braking, which allows for further control of the vehicle when driving on track.

STAGE 2

034Motorsport Stage 2 Performance Software for the EA888 Gen 1 2.0 TSI engine is engineered to further increase horsepower and torque with the addition of a high-flow downpipe upgrade and performance air intake. 034Motorsport's calibrations optimize the factory ECU for these hardware modifications in order to extract additional power from the 2.0 TSI engine.

Stage 2 Performance Software features a higher redline of 7,000 RPM, resulting in a broader, more usable powerband. In addition to power improvements, 034Motorsport's engineers spent a significant amount of time refining the throttle mapping in order to provide improved throttle response and allow for more precise throttle modulation. Stage 2 Performance Software also enables left foot braking, which allows for further control of the vehicle when driving on track.

034MOTORSPORT EA888 Gen 1 2.0 TSI MED17 ECU PERFORMANCE SOFTWARE HARDWARE REQUIREMENTS

Stage	Required Modifications	Recommended Modifications
Stage 1	No hardware required	034Motorsport Performance DSG Software (if applicable)
Stage 2	High-Flow Downpipe Upgrade Performance Air Intake System	Performance Intercooler Upgrade 034Motorsport Performance DSG Software (if applicable)

034Motorsport Dynamic+ End User Flashing Kit

034Motorsport's Dynamic+ End User Flashing Kit allows customers to install their 034Motorsport Dynamic+ Performance Software themselves. In addition, End User Flashing allows Dynamic+ Performance Software customers to receive and install software updates and revisions, flash back to stock, or upgrade to the next stage of performance software for their vehicle.

Requirements for End User Flashing:

• Windows 7 or Windows 10 Laptop with Available USB Port
• Power Supply for Laptop
• Secure Wired (Or Very Stable WiFi) High-Speed Internet Connection
• CTEK Trickle Charger (Or Similar)
• Available Electrical Outlets

034Motorsport End User Flashing Kit Contents:

• 034Motorsport OBD-II Adapter
• USB-A to USB-B Cable
• Carrying Case
• User Credentials (Provided Via Email)

EMISSIONS DISCLAIMER

• This product is sold for racing use as well as use on vehicles not registered for on highway use.
• By purchasing this product, you understand that this product is sold for racing use as well as used on vehicles not registered for on highway use, and that it is not legal for use on highway or street vehicles.

Please Note: Crackle results may vary based on ECU box code variations, fuels, exhaust setup, and geographic locations. 034Motorsport also offers no-crackle files available upon request. Please email Tuning@034Motorsport.com for more information if you do not see them in your flashing portal.

⚠️CALIFORNIA WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
