034Motorsport Dynamic+ ECU & TCU Tuning Bundle for MK7 / MK7.5 / 8V / 1.8T EA888.3 | 034-103-2820

To see full app features and access helpful How-To YouTube videos: Click Here

Detailed Flashing Features:

• Complete Any ECU Or TCU Tune Flash
• Quickly Flash Different Fuel Octane Or Transmission Files
• Flash ECU/TCU Using Mobile Device's Internet Connection
• Enhanced Flashing Protocol Protections For Increased Flashing Stability
• User-Configurable Live Data Displays
• Multiple Data Display Views
• Dozens Of Defined Variables Available
• High-Speed Datalogging Of Pre-Defined Variables
• Easy Upload Of Logs To 034Motorsport Server
• Datalog Analysis Services Available Free Of Charge
• Read & Clear DTCs On ECU & TCU
• View Emissions Monitor Statuses
• Perform Adaptations/Recalibrations*
  • *Available for limited platforms, coverage expanding regularly



    ECU SOFTWARE FEATURES:

    	Increased Horsepower & Torque Throughout the Powerband		True Launch Control Functionality for Improved Acceleration Times		Available in 87 Octane, 91 Octane, 93 Octane & E85 (Ethanol) Calibrations
    	Track-Tested Calibrations Ensure Consistent Power Delivery		Refined Throttle Mapping for Enhanced Throttle Response & Precision. Left Foot Braking Enabled		Improved Power Delivery, Acceleration, and Driving Characteristics
    	Speed Limiter Removed for Increased Top Speed		Flashed Directly Via the Factory OBD-II Port


    034MOTORSPORT MK7/7.5 VOLKSWAGEN GOLF, SPORTWAGEN, ALLTRACK, & 8V AUDI A3 1.8T PERFORMANCE SOFTWARE COMPARISON:

    STAGE	FUEL	MAX HP	MAX TQ	MAX HP GAIN	MAX TQ GAIN	REV LIMITER*	SPEED LIMITER
    Stock (IS12)	87 Oct (AKI)	179 HP	211 TQ	NA	NA	6,500 RPM	124 MPH
    Stage 1 (IS12)	87 Oct (AKI)	214 HP	272 TQ	45 HP @ 4,600 RPM	67 TQ @ 3,200 RPM	6,500 RPM	∞
    Stage 1 (IS12)	91 Oct (AKI)	230 HP	291 TQ	60 HP @ 4,600 RPM	89 TQ @ 3,400 RPM	6,500 RPM	∞
    Stage 1 (IS12)	93 Oct (AKI)	238 HP	301 TQ	68 HP @ 4,800 RPM	98 TQ @ 3,300 RPM	6,500 RPM	∞
    Stage 1 (IS12)	E85 (AKI)	261 HP	322 TQ	91 HP @ 5,000 RPM	119 TQ @ 3,300 RPM	6,500 RPM	∞



    ***All octane ratings are in US standard AKI (RON+MON). Some ROW countries such as the UK use a RON octane rating that differs from US Octane ratings. Please email tuning@034motorsport.com to ensure you are running the correct octane file for your area. Running the incorrect octane file for your fuel can result in irreversible damage.

    DYNAMIC+ ECU FEATURES:

    THERMAL MANAGEMENT SAFETY STRATEGIES:

    With increased power, comes increased heat. With increased heat, comes the need for additional management. For charge air temperature, 034Motorsport has implemented key safety features to keep your engine running optimally and safely in virtually any condition - just like the OEM calibration. Substantial effort was spent on balancing the trade off of charge temp for power, and improving the compressor efficiency so that it doesn't generate too much charge temp.

    Charge Air Temp: When the charge temp exceeds 70*C there is a reduction in power output. When the charge temp exceeds 80*C there is a more significant reduction in power output. This charge temp limitation is there to prevent knock events, which can severely damage a motor. With these safety measures in place, you can confidently drive your car, from the top of Pikes Peak to Death Valley, knowing the factory ECU has optimal performance and safety covered.

    Oil Temperature: When oil temperatures exceed 130*C there is a reduction in power output. When the oil temperature exceeds 135*C there is a more significant redution in power output. This oil temperature limitation is there to limit oil temperatures from climbing to unsafe levels which can damage a motor. With these safety measures in place, you can confidently drive your car under high sustained loads, such as track driving or towing, knowing the factory ECU has optimal performance and safety covered.

    FUEL SYSTEM OPTIMIZATION:

    While E85 provides substantial increases in power, it requires about 30% more fuel than standard pump gasoline per ignition cycle. Utilizing a variety of fuel stratified injection strategies, 034Motorsport calibrators have further optimized the factory fueling system to be able to adequately support full E85 on factory hardware for Stage 1.

    ADVANCED BOOST CONTROL STRATEGIES

    From sea level to 6,000+ ft elevation in the Rocky Mountains, to below freezing and over 100° Fahrenheit, Dynamic+ employs advanced boost control and safety strategies to ensure that your IS12 equipped EA888.3 1.8T is consistently reliable, regardless of the conditions! These advanced boost control calibration strategies ensure that your turbocharger stays within its safe operating range and generating consistent boost levels, while preventing premature failure, especially when your vehicle is in less than ideal environments.

    FREE REVVING IN NEUTRAL AND PARK

    The rev-limiter is now removed while in Neutral and Park. Impress friends and annoy those around you with limitless ease!

    LAUNCH CONTROL OPTIMIZATIONS FOR DQ250 EQUIPPED VEHICLES:

    034Motorsport’s skilled Calibration team has properly engineered and implemented an advanced motorsport derived strategy for building boost during launch control. Dynamic+ Calibrations allow for launch control to build boost more quickly and efficiently as opposed to the factory calibration without damaging the turbocharger.

    REV HANG REMOVED

    034Motorsport Dynamic+ Tuning removes rev hang from manual transmission equipped vehicles for a smoother driving and shifting experience!




    DQ250 6-SPEED DSG TCU TUNE FEATURES:

    Flashed directly through your vehicle’s OBD-II port, 034Motorsport’s proprietary calibrations for the DQ250 TCU safely and effectively optimize its operation for Stage 1 Dynamic+ Performance ECU Software. The DQ250 6-Speed DSG transmission is found in the MK7/7.5 Volkswagen Golf, Sportwagen, Alltrack, & 8V Audi A3 1.8T. 034Motorsport Performance DSG Software also increases the shift speed and optimizes the shift points in Drive and Sport modes for better performance and driveability. The result is a noticeable improvement in acceleration, without any sacrifice in comfort or reliability.

    Features:
    • Shift Speeds Increased
    • Optimized Shift Points in Drive & Sport Mode
    • Increased DSG Clutch Clamping Force
    • Improved Responsiveness
    • No Kickdown Downshifts in Manual Mode
    • Launch Control Enabled on All Models
    • Gear Display Indicator on MFD Enabled in All Driving Modes

    034MOTORSPORT EA888 GEN 3 1.8T STAGE DESCRIPTIONS:

    STAGE 1

    034Motorsport Stage 1 Performance Software for the EA888 Gen 3 1.8T engine running pump gas or ethanol is engineered to safely increase the horsepower and torque with no additional hardware required.

    In addition to power improvements, 034Motorsport's engineers spent a significant amount of time refining the throttle mapping in order to provide improved throttle response and allow for more precise throttle modulation and further control of the vehicle when driving on track. Due to the limitations of the stock turbocharger on the EA888 Gen 3 1.8T, the rev limiter was not adjusted.

    034Motorsport EA888 Gen 3 1.8T Performance Software is flashed via the factory OBD-II port, and does not require any physical modification of the factory ECU. Dynamic+ ECU Software is compatible with DQ250 DSG, 6MT, and Aison AQ250 transmission equipped vehicles. Stage 1 is available in 87 Octane, 91 Octane, 93 Octane, and E85. ALL FILES ARE US (MON+RON) RATING, ROW OCTANE RATINGS MAY DIFFER. IF YOU ARE A UK/ROW CUSTOMER, PLEASE EMAIL TUNING@034MOTORSPORT.COM FOR ASSISTANCE ON FUEL MAP SELECTION.




    ECU TUNE SUPPORTING MODIFICATION REQUIREMENTS:



    STAGE	REQUIRED MODIFICATIONS	RECOMMENDED MODIFICATIONS
    Stage 1 87/91/93	No Hardware Required!	Dynamic+ TCU Tune S34 Intake System 034Motorsport Upgraded Turbo Inlet Upgraded Intercooler System Upgraded Clutch (Manual Transmissions Only)
    Stage 1 E85	No Hardware Required!	Dynamic+ TCU Tune S34 Intake System 034Motorsport Upgraded Turbo Inlet Upgraded Intercooler System Upgraded Clutch (Manual Transmissions Only) Ethanol Content Sensor/Gauge Better Tires!

    REAL-WORLD PERFORMANCE DATA

    034Motorsport saw improvements of over 2-seconds quicker in the quarter mile, trapping over 14 MPH quicker over the stock quarter mile. Similarly, 034Motorsport also observed nearly a 3-second improvement in the 0-60 MPH time! These times were collected by 034Motorsport in our development Stage 1 Golf Alltrack with stock hardware, wheels & tires, and no weight reduction.

    • Stock (87 AKI):
      • Quarter Mile: 15.67 @ 86.11 MPH (-284 FT DA)
      • 0-60 MPH: 7.62s
      • Dragy: Click Here
    • Stage 1 (87 AKI):
      • Quarter Mile: 14.02 @ 95.03 MPH (-1806 FT DA)
      • 0-60 MPH: 5.53s
      • Dragy: Click Here
    • Stage 1 (91 AKI):
      • Quarter Mile: 13.89 @ 95.88 MPH (-43 FT DA)
      • 0-60 MPH: 5.39s
      • Dragy: Click Here

    • Stage 1 (93 AKI):
      • Quarter Mile: 13.70 @ 97.75 MPH (-272 FT DA)
      • 0-60 MPH: 5.18s
      • Dragy: Click Here
    • Stage 1 (E85):
      • Quarter Mile: 13.35 @ 100.59 MPH (-77 FT DA)
      • 0-60 MPH: 4.87s
      • Dragy: Click Here

    034MOTORSPORT DYNAMIC+ END USER FLASHING KIT R4:

    034Motorsport's Dynamic+ End User Flashing Kit R4 allows customers to install their 034Motorsport Dynamic+ Performance Software themselves. In addition, End User Flashing allows Dynamic+ Performance Software customers to receive and install software updates and revisions, flash back to stock, or upgrade to the next stage of performance software for their vehicle.

    Available at no additional charge is the 034SPI Mobile App, which allows you to easily flash your car, change fuel maps, configure live data displays, record and submit data logs to 034Motorsport's Tuning Support team, and utilize diagnostic support tools such as DTC/CEL code read/clear and more all from your mobile device! Available via the Apple App Store or Google Play Store.

    Requirements for Windows-Based End User Flashing:

    • Windows 10/11 Laptop with Available USB Port
    • Power Supply for Laptop
    • Secure Wired (Or Very Stable WiFi) High-Speed Internet Connection
    • Battery Charger, 20AMP minimum (CTEK Brand recommended)
    • Available Electrical Outlets

    Requirements for 034SPI App End User Flashing:

    • Dynamic+ End User Flashing Kit R4
    • Apple Silicon-Based Mac Laptops (M1, M2, M3)
    • Apple iPhone or iPad Devices
    • Android Phone or Tablet Devices
    • Power Supply for Device (If Low Battery or Poor Health)
    • Secure and Stable WiFi or LTE High-Speed Internet Connection
    • Battery Charger, 20AMP minimum (CTEK Brand recommended for first flash)
    • Available Electrical Outlets

    034Motorsport End User Flashing Kit R4 Contents:

    • 034Motorsport OBD-II Adapter
    • USB-C to USB-A Cable
    • USB-C to USB-C Cable
    • Carrying Case
    • User Credentials (Provided Via Email)

    EMISSIONS DISCLAIMER

    • This product is sold for racing use as well as use on vehicles not registered for on highway use.
    • By purchasing this product, you understand that this product is sold for racing use as well as used on vehicles not registered for on highway use, and that it is not legal for use on highway or street vehicles.

    WELCOME TO DYNAMIC+ TUNING!

    034Motorsport's Dynamic+ Performance Software provides reliable horsepower and torque increases through driver-centric calibrations that elevate driving enjoyment and precision. The Dynamic+ Tuning Philosophy emphasizes safety and reliability, with the goal of optimizing power delivery without compromising the longevity of the engine and related components.

    Included with the Purchase of Any Dynamic+ Tune:

    • 30 Day Money Back Guarantee
      • 034Motorsport offers a 30 Day Money Back Guarantee on Dynamic+ ECU & TCU Tuning Software & Flashing Cable to ensure your complete satisfaction with our products and tuning. If you are not 100% satisfied with the Dynamic+ Transformation on your Volkswagen or Audi, please email tuning@034motorsport.com within 30 calendar days of the initial flash, and we will process a full refund to the original payment method.
    • Easy Map Switching
      • When purchasing any 034Motorsport staged tune, all octanes for that specific tune are included, as is the vehicle’s stock file.
      • Switching files is easy when using the Dynamic+ Flashing Portal on your Windows 10/11 computer, with mobile support available now!
    • World Class Tuning Support
      • 034Motorsport’s World Class Tuning Support Team is available 5 days a week standing by to answer and assist with any questions you may have regarding your Dynamic+ Tune, recommended hardware upgrades, or help to diagnose any issues you may have with your vehicle while flashing, or after you’ve flashed.
    • Advanced Technological Support
      • The 034Motorsport Dynamic+ Tuning Suite also offers enhanced to users to allow users to datalog their Volkswagen or Audi to ensure that it is running properly. This logger is available to be used with our Tuning Support Team and is not designed to be reviewed by the end user.

    • 034Motorsport Dynamic+ Flashing Portal:

      • Click Here to Download for Windows 10/11 PC
      • Click Here to Download For iPhone/iPad/iMac
      • Click Here to Download For Android
